Juniper EX2200-48P-4G - Image 1
Cisco Catalyst 4500-X Series
Cisco ME-3400EG-2CS-A

Juniper EX2200-48P-4G

  • CPU: 800 MHz ARM CPU
  • DRAM: 512 MB
  • Flash: 1 GB
  • Switching Engine: Store and forward
  • OS: Junos OS with a single control plane
  • Management: Built-in J-Web interface, integrates with Junos Space

Port Density & Connectivity

  • Varies by Model: The number of host and uplink ports depends on the specific EX2200 model.
  • Example (EX2200-24P-4G): 24 host ports + four-port GbE uplinks
  • Example (EX2200-48T-4G): 48 host ports + four-port GbE uplinks
  • Uplink Ports: Typically includes a four-port GbE uplink module.



Performance & Features

  • Packet Switching Capacity: Scales with model, e.g., 56 Gbps for the EX2200-24P-4G and 104 Gbps for the EX2200-48P-4G.
  • Layer 2 Throughput: Example: 41.7 Mpps for the EX2200-24P-4G at wire speed.
  • Security & Policies: Supports port security, DHCP snooping, DAI, MAC limiting, and QoS policy enforcement.
  • VoIP/Video Ready: Designed to support voice and video traffic.

Environmental

  • Operating Temperature: 0 to 45 °C
  • Humidity: Up to 85%
       Included Accessories RJ-45-to-DB-9 serial port adapter, 19-inch rack mount kit, Connector retainer, and Power             cord for the country of shipment.
Category:

Description

Juniper EX2200 48P:

The EX2200 is a low-power, low-acoustic switch for branch and campus networks. Start here to evaluate, install, or use the Juniper Networks® EX2200 Ethernet Switch. The EX2200 is a low-power, low-acoustic switch for branch and campus networks.
